Energy-saving mesh cable tray specifications table

Mesh cable trays are available in multiple widths, heights, and surface treatments, designed for efficient cable routing, ventilation, and load support.OverviewEnergy-saving mesh cable trays are designed to support and route power, data, and control cables while providing high ventilation, easy cable access, and reduced material usage. They are suitable for industrial, commercial, and data center applications, with operating temperatures ranging from -20°C to +120°C depending on material and coating . Mesh trays allow simple creation of bends, branches, and exits due to separable wires and flexible bending capacity .Standard Dimensions and SpecificationsParameterTypical Range / OptionsNotesWidth (inside usable)50 mm – 600 mmNominal width; outside width slightly larger due to side rails Height / Depth50 mm, 75 mm, 105 mmHigher trays provide greater cable capacity and load support Length2 m, 3 mStandard straight sections; can be cut or bent on siteMaterial Thickness1.5 mm – 2.5 mmDepends on load requirements and surface treatmentSurface TreatmentsElectro-zinc, hot-dip galvanized, stainless steel, Zinc+Corrosion protection for indoor/outdoor environments Load CapacityLight to medium duty (varies by height and width)Patented double transversal wires increase working load Bend / Branch CapabilityFlexibleCan create bends, junctions, and exits without additional accessories Cable Types SupportedPower, data, control, fiber opticSuitable for mixed cable installations Key FeaturesHigh ventilation reduces heat buildup and energy loss in cable systems .Flexible installation: screw-less accessories and fast-fix locking clips allow on-site customization .Compliance: Designed to meet NEC, NEMA, and IEC standards for cable fill, structural load, and safety .Energy efficiency: Open mesh design minimizes material usage while maintaining structural integrity and load capacity .Selection TipsDetermine cable fill: Choose width and height based on the number and type of cables.Consider environment: Select surface treatment for corrosion resistance.Plan for bends and branches: Use flexible mesh trays to reduce the need for pre-fabricated fittings.Check load requirements: Ensure tray height and wire configuration support the expected cable weight. These specifications provide a comprehensive guide for selecting energy-saving mesh cable trays suitable for a wide range of installations, ensuring both efficiency and compliance with industry standards .
